2000W Laser Rust Removal Machine

2000W laser rust removal machine

1、 Product positioning: Industrial grade high-efficiency and environmentally friendly rust removal benchmark

The 2000W water-cooled fiber laser rust removal machine is a surface treatment core equipment specially designed for medium and heavy-duty industrial scenarios. It integrates 1070nm fiber laser technology with an intelligent closed-loop water cooling system, based on the core principle of "non-contact molecular level peeling", completely replacing traditional sandblasting, acid washing, and polishing processes. The equipment focuses on the removal of stubborn attachments such as thick rust layers, heavy oil stains, and multi-layer coatings, and combines efficient operation with non-destructive protection of substrates. It is widely used in fields such as mechanical manufacturing, ship and ocean, automobile maintenance, and cultural relic restoration, and is an ideal choice for enterprises to achieve green production, cost reduction, and efficiency improvement. ​

2、Core Technical Parameters - [2000W Laser Rust Removal Machine]

Laser power: 2000w Suitable for light/medium/severe corrosion, balancing efficiency and precision processing.
Laser wavelength: 1070nm ± 20nm fiber laser, metal absorption rate ≥ 90%, more thorough gasification and peeling of rust layer.
Heat dissipation method: Intelligent closed-loop water cooling system, temperature control accuracy ± 1 ℃, supports 24-hour continuous heavy-duty operation without attenuation.
Rust removal efficiency: 20-40 ㎡/h for conventional rust removal and 10 ㎡/h for severe rust removal; 3-5 times higher than traditional polishing processes, significantly reducing the operating cycle.
Cleaning scope: rust, oxide scale, multi-layer paint, heavy oil stains, coatings, welding slag, etc., one-stop solution for various stubborn attachments on metal surfaces.
Work performance: Scanning speed of 10-2000mm/s, maximum cleaning width of 300mm; outstanding efficiency in large-scale operations, suitable for processing large components.
Operating radius: Equipped with 10m fiber optic cable as standard, it allows for unrestricted long-distance operations and is suitable for complex working conditions and mobile needs.
Working distance: optimal 65-75cm; flexible to handle workpieces of different sizes and shapes.
Power supply requirements: single-phase 220V ± 10%, 50/60Hz [customizable], total power ≤ 9KW; industrial standard power supply, suitable for stable operation in the workshop.
Working environment: Temperature range of 10-40 ℃; Humidity ≤ 70%, no condensation. Adapt to various application scenarios such as workshops and outdoors.
Security configuration: laser level 4 protection, multiple alarms; Ensure the safety of operators and comply with industrial safety standards.

3、Seven core advantages -2000W laser cleaning machine

3.1 High energy and efficiency, fast removal of thick rust
The 2000 watt high-power laser has outstanding focusing energy density, which can instantly raise the temperature of rust layers and coatings to the gasification point. Combined with 20000mm/s high-speed scanning, only 1-2 scans are required to process oxide scales up to 200 μ m thick, with an efficiency increase of 40% compared to traditional sandblasting. It can complete 20-30 square meters of severe rust treatment in a single day, greatly reducing labor costs. ​
3.2 Water cooling and constant temperature, stable heavy load
The intelligent closed-loop water cooling system precisely controls the temperature of the laser module, avoiding overheating and attenuation during high-power operations. It supports 7 × 24-hour uninterrupted operation and has a core component lifespan of over 50000 hours. Compared to air-cooled models, the heat dissipation efficiency is increased by three times, and the stability is better in high temperature or continuous production scenarios in summer. ​
3.3 Non destructive cleaning to protect the substrate
By using the "selective absorption" technology, the laser only acts on the pollutant layer, and the substrate is almost unaffected due to its high reflectivity.
3.4 Green environmental protection, zero pollution compliance
There are no chemical agents, no dust splashes, and no wastewater discharge throughout the process. Only a small amount of recyclable rust powder is generated, which meets ISO14001 environmental standards. Compared to acid washing process, it can reduce 10-15 tons of chemical pollutant emissions annually, completely solving the environmental compliance pain points of traditional processes. ​
3.5 Flexible adaptation, full scene coverage
Flexible operation: Lightweight handheld laser gun for more flexible operation; ​
Widely applicable: supporting various metals such as carbon steel, stainless steel, aluminum alloy, etc., it can be used for multiple processes such as pre welding pretreatment, post welding slag cleaning, equipment refurbishment, etc; ​
Strong scalability: It can be manually operated or combined with robot automation operations, suitable for different needs such as large components and batch workpieces. ​
3.6 Intelligent and convenient, easy to learn
Equipped with an intelligent touch screen, it can quickly adjust parameters such as power and scanning width, and beginners can work independently after 1 hour of training. Support parameter storage and calling, eliminating the need for repeated debugging for different materials and corrosion levels, improving job consistency. ​
3.7 Long term low consumption, outstanding cost-effectiveness
No consumables such as sandpaper, grinding wheels, chemical agents, etc., only regular cleaning of optical lenses is required, with low single maintenance costs. The photoelectric conversion efficiency is high, and the energy consumption per square meter is only one-third of traditional processes. The comprehensive cost of long-term use is reduced by 40% -60% compared to sandblasting and acid washing. ​

4、 Core applicable scenarios -2000W laser rust removal machine

4.1 Mechanical manufacturing industry: Rust layer removal and surface pretreatment of machine tools, molds, and mechanical parts to ensure subsequent processing accuracy;
4.2 Marine industry: removal of rust and attachments on ship decks, offshore platforms, and port machinery; ​
4.3 Automotive maintenance/manufacturing: rust removal and refurbishment of automotive chassis and engine components, cleaning of welds before welding, and improving welding strength by 15%;

4.4 Bridge infrastructure industry: corrosion maintenance of steel structure bridges, iron towers, and scaffolding, suitable for high-altitude and long-distance operation needs;
4.5 Hardware processing industry: surface rust removal and coating peeling of hardware accessories and stamping parts, to improve the quality of spraying, electroplating and other processes;
4.6 Other fields: Surface cleaning and maintenance of power equipment, chemical pipelines, and aerospace components.

5、 Quality assurance and exclusive services

Provide a one-year warranty for the entire machine and free online remote technical support. Our professional after-sales team responds 24 hours a day, provides free online operation training, regularly follows up on equipment usage, and promptly solves any problems encountered by users during use. At the same time, we provide vulnerable parts supply to ensure that users have no worries.

We can provide pulse laser cleaning machines with different powers such as 100W/200W/300W/500W/1000W, as well as water-cooled handheld fiber laser rust removal machines with different laser powers such as 1500W/2000W/3000W/6000W. If you happen to need laser cleaning/rust removal machine equipment, you can contact us for the latest product factory prices. We look forward to sincere cooperation with you.
